Trolling Motor Batteries

Advantages

Features

Longer Cycle Life-The brand-new brand A cell has remarkable consistency and balance, prolonging the service life of lithium battery.
Lighter Weight—Its weight is about 40% of that of the same type of lead-acid battery, saving space and reducing weight.
Safer materials -ILUMA lithium batteries are characterized by their acid-free, heavy metal-free composition, corrosion resistance, heat resistance, waterproofing, and overall environmental friendliness.
Smarter BMS- BMS ensures balanced voltage and current, activating protection functions automatically in case of a short circuit.
Powerful Communication Features-Compatibility with communication protocols such as APP, Bluetooth, CAN, and RS485, coupled with high-definition visual display settings, enables easy monitoring of battery status and performance.
Waterproof IP67- Excellent temperature adaptability, within environments ranging from -20℃ to 60℃，No fear of water.
Self-heating function- The integrated heating function enables charging and usage below zero temperatures, ensuring reliability even in cold weather conditions.

Types and Uses of Trolling Motor Batteries

ILUMA's LiFePO4 technology provides more powerful energy for your trolling motor. ILUMA 12V LiFePO4 batteries offer superior performance and safety for your trolling motors with lighter weight, longer lifespan, and more stable output. There are different types of batteries to meet various needs:

1. Starting Battery

This battery is typically used to deliver the high power needed to start marine engines. It is mainly utilized on fishing boats equipped with traditional internal combustion engines to power ignition systems and electronic equipment.

2.Deep Cycle Battery

Designed for continuous and long-term power supply, this battery is ideal for trolling motors and shipboard power supplies such as sound systems, fish finders, and GPS devices. It meets the needs of trolling motors, marine electronics, and auxiliary power supplies. These batteries are durable and long-lasting, with a deep cycle capacity of up to 6,500 cycles and a lifespan of up to 10 years.

3. Dual-Purpose Battery

This battery serves both as a starting battery for the engine and as a deep cycle battery for the fishing boat. It can start the engine and also be used in marine electronic equipment to meet your multifunctional needs. Compact and portable, the dual-purpose battery saves space and reduces load, making it the top choice in its category.

Trolling Motor Batteries

ILUMA LiFePO4 batteries for trolling motors feature a high waterproof rating, built-in sealing ring, and a waterproof and flame-retardant housing. These batteries are waterproof to IP67 and have been tested for corrosion resistance in both water and saltwater, making them ideal for trolling motor use. The robust internal structure protects the battery from the risk of short-circuits caused by vibration or shock, eliminating the need for frequent maintenance and ensuring low battery usage.

The structure is upgraded and optimized to be lightweight and compact while improving performance and capacity, making it perfect for your trolling motor. With our LiFePO4 battery, you can enjoy your fishing trips and seascapes with peace of mind. The 12V battery is an ideal choice for your boat, saving you power, time, and costs, ultimately providing more economic benefits.

FAQ

Q: How to Choose the Right Capacity of Trolling Motor Batteries？

A: The capacity of the lithium battery required for a trolling motor depends on several factors, including the thrust rating, duration of use, and the environment in which it is used.

Thrust Rating:

- 50-55 lbs thrust: Typically, a 12V lithium battery with a capacity between 50Ah and 100Ah is sufficient.

- 55-80 lbs thrust: A 12V lithium battery with a capacity between 100Ah and 125Ah is generally recommended.

- 80 lbs and above thrust: You may need a 24V or 36V system with a capacity of 100Ah or more.

Duration of Use:

- For extended use (e.g., 8 hours or more), consider a higher capacity battery to ensure you don’t run out of power during your outing.

Environment of Use:

- If you often run your motor at maximum power, use spot locks frequently, or fish in strong currents or windy conditions, you'll need a battery with at least 100Ah capacity.

Common Configuration Options:

- 12V 50Ah to 100Ah lithium batteries: Suitable for small to medium-sized trolling motors and short to moderate use.

- 12V 100Ah to 125Ah lithium batteries: Ideal for medium to large trolling motors and long or intensive use.

- 24V or 36V systems: Best for large trolling motors or applications requiring longer range and extended power.

Q: Do I need to fully charge my newly purchased trolling motor batteries before using it?

A: When you purchase a new lithium trolling motor batteries, it typically comes charged to about 50% to 60% for safe transportation and storage purposes. Lithium batteries are not affected by memory effects, so they can be used at any charge level. If you're only testing the new battery briefly or using it for a short distance, you can use it directly. However, if you plan to use it extensively at sea, it's recommended to fully charge the battery beforehand to ensure sufficient power during use.

Q: How long does it take to charge 12.8V 100Ah lithium trolling motor batteries?

A: Battery charging time depends on the capacity rating of the battery and the output of the charger. For example, if a 12V lithium charger is rated at 15 amps, then you can fully charge a 12V 100Ah battery in approximately 6 hours.

Q: Do lithium Trolling Motors batteries require a charger that is professionally configured？

A: Lithium batteries possess unique charging characteristics. Professionally configured chargers typically incorporate safety features like temperature monitoring, overcharge protection, and balancing functions to safeguard the battery during charging. Utilizing a charger specifically designed for lithium batteries prevents overcharging or undercharging, thereby preserving optimal performance and capacity throughout its lifespan.

Q: What battery does a trolling motor need?

A: LiFePO4 trolling motor Batteries are the best choice for trolling motor batteries, depending on the size and type, a 12 V deep cycle battery with 100ah or more. The higher the amp-hour rating, the longer the trolling motor will run.

Q: What is the most durable and stable trolling motor batteries?

A: LiFePO4 batteries have the longest life of any deep-cycle battery. In the current market, LiFePO4 batteries are the most in-demand trolling motor battery for any crew or angler.

Q: How long will a 12V 125Ah LiFePO4 battery last when using a trolling motor?

A: For example, if your trolling motor draws 10 amps per hour and the deep cycle battery is rated for 125ah, that means you can run your trolling motor for 12 hours.

Q: What size lithium battery is the best choice for trolling motor batteries?

A: If we need a trolling motor with a kayak, a smaller lithium trolling motor battery can be used (e.g. 12V 50Ah or 12V 80Ah battery). If you need a battery that is as light and small as possible, with a higher energy density, then the advantages of lithium batteries are significant.

Q: What size battery do I need for a 55lb thrust trolling motor?

A: Considering the physical power of the trolling motor and the number of batteries selected, if the motor has a maximum thrust of 55 lbs, (1) 12V lithium battery. If the maximum thrust is 80 lbs, you will need（2）12-volt batteries for a total of 24 volts.

Q: Can my trolling motor batteries be replaced with car battery?

A: Adopt a deep cycle or marine battery, the LiFePO4 battery is a good choice.

Q: What problems will lithium trolling motor batteries cause if I use the wrong charger?

A: Lithium batteries can be damaged if the wrong charger used， the voltage and current do not match; using a special charger is safer, and can also charge the lithium battery more quickly.

Q: Can Trolling motor batteries overcharge?

A: Lithium-ion batteries contain a lithium-ion membrane for higher energy, higher safety, and a built-in BMS to protect the battery from overcharging and over-discharging and to maximize the cycle life of the battery.

Q: Is it best for me to keep my Li-Ion batteries fully charged and in a fully charged state?

A: If you plan to store the lithium battery and not use it for a long period, recommending to keep the lithium away from a charge of about 50% or so. If you frequently fully charge the battery before storing it, it may cause the performance of the battery to deteriorate.

Q: Is it okay to leave lithium trolling motor batteries connected to charger overnight?

A: Generally speaking, it is safe. However, please note that it needs to be kept in a cool and dry place to avoid overheating the generator, so it is best to unplug it if it is not in use.

Q: How often should the Trolling motor batteries recharge when not in use?

A: We recommend that all lithium batteries that are not in use undergo a complete check and maintenance cycle at least once every 3-6 months to check the charge level (typically 40-60%) and recharge appropriately to maintain a certain level of charge that will prolong the life of the battery.

We're professional trolling motor batteries manufacturers and suppliers in China, specialized in providing high quality customized service. We warmly welcome you to wholesale trolling motor batteries at competitive price from our factory.
